H-301 Libelle

Specifications:


Wing Span: 2.58 m (101.5")
Wing Area: 29.8 dm2 (461 sq. in.)
Wing Airfoil: MH 32 mod.
Wing Loading: 48 g/dm2 (14.5 oz/sq. ft.)
Flying Weight: 1.42 kg (50 oz)
Radio: Standard radio
Sub-Micro servos in wings


The H-301 Libelle was produced between 1964 and 1969 byformer Glasflügel director and designer Eugen Hanle and Wolfgang Hutter. It was the first all composite glider that was produced in substantial quantities (over 100 units). It was also the base for the upcoming series H-20x Libelle and the famous Salto (thus the similarity of the fuselage design).

This H-301 Libelle is a really nice semi-scale reproduction at 1:6 scale and comes as an all molded kit and is highly finished. This model is well suited for slope flying, but will do well on a good thermal day and can be histarted or winched. It is also suited aero towing or even for electric conversion. Nice smooth handling, without any bad habit. It has an extended flight envelope thanks the flaps, which allows easy landing in restricted aera.

The kit comes completely finished. The wings are hollow moulded, ailerons and flaps are hinged. Moulded winglets are removable. The tail is bolt on and so removable for ease of transportation. The clear plastic canopy is fitted to the fiberglass tray, molded seat and interior are finishing the cockpit. Retractable landing gear is installed. All what's required is your radio gear. You will need 4 sub-micro servos, 3 micro servos and a small 6 channel receiver.

H-301 Libelle (2.58 m) FG RTF kit, price: 529.00U$
