Alexis-VE and XE

Specifications:


Wing Span: 2.5m (99")
Length: 1.4 m (55")
Wing Area: 42.5dm2 (658 sq. in.)
Wing Airfoil: MH-43
Wing Loading: 41g/dm2 (13 oz/sq. ft.)
Flying Weight: 1.7-2.0 g (60-70 oz)
Radio: Sub Micro servos and micro receiver recommended
Motor: Mega 3S
HP220/20/A2 P4 5:1



Electric multi-task and performance motor glider

Alexis VE and XE is a 2.5M span fully moulded electric soarer that fills the gap between the 2m and 3m moulded ships. Install a brushless motor and the performance is blistering. The model travels the sky with ease. Its clean lines and beautifully moulded surfaces add to its desirability. With flaps and ailerons control response is quick and accurate. Aerobatics and fast turns are simple with this machine! The fuselage is 2.4Ghz friendly, the wing is fully moulded fiberglass with carbon reinforcement and very strong but light. A major 20x14mm Carbon joiner attaches the wings to the fuselage. Six servos are required for the control surfaces. The kit contains a full hardware pack. A few evenings work will have you climbing into the clouds and soaring like an eagle!

Kit is easy to assemble and can be done within few hours
Easy to carry around with its two piece wings and removable V or +tail
Comes with flaps and ailerons for easy landing.

Kit content:

Fiberglass fuselage, carbon reinforced.
Two piece wings hollow molded, carbon reinforced.
Molded V-tail, removable, or flying stab removable
remaining hardware

Recommended Power setups:

Moskito 3G on 3S LiPo, for softliner setup (400W)
Mega 22 3S on 3S LiPo, for hotliner setup (600W)
HP 220/20/A2 P4 5:1, hotliner setup (1kW)
Mega 22/45/3E on 4S (850W)_
Mega 16/25/1.5S PG 3.8:1/4.3:1 (1kW)
Mega 16/35/1 PG 6:1, Mega F5J (2-4kW)

Combo packages available upon request

Alexis-VE v-tail configuration, price: 649.00 U$, on sale 629.00 U$
Alexis-XE cross-tail configuration, price: 759.00 U$, on sale 729.00 U$
